| Machine Model |
AU2.0I-C PLUS CAB |
| Style & Type |
¡®I¡¯style=longitudinal flow, full-feeding, rubbertrack, self-propelled |
| Suitable Crop |
Paddy, Wheat, Barley |
| Working dimension L¡ÁW¡ÁH, |
5530¡Á2830¡Á2860 mm |
| Weight (empty tank), |
3850kg |
| Min. ground clearance, mm |
260mm |
| Ground clearance (under axle house) |
280mm |
| Harvesting capacity |
0.23~0.95ha/hour |
| Feed rate |
5.0kg/second |
| Engine |
Model |
Changhai 4G33TC EURO-III Standard |
| Power |
99Hp/2600RPM |
| Fuel tank |
110L |
| Rubber track |
Specification |
500*90*51 |
| Walking gearbox |
Type |
YZ80-3 Mechanical gearbox+HST----> stepless transmission |
| Gear |
Main gear: forward+reverse; Auxiliary gear: low, harvesting, high |
| Walking speed |
Forward |
Low gear:0-1.43m/s, Harvesting gear: 0-1.87m/s, High gear: 0-2.65m/s |
| Reverse |
| Steering type |
Hydraulic, brake+clutch change |
| HST |
45L |
| Reel |
Type |
Tine bars + Eccentric bar frames |
| Diameter |
¦µ900mm, 5bars |
| Cutter table |
Control type |
Hydraulic |
| Cutting width |
2.4 m |
| Diameter of head auger |
¦µ318mm (option: 380mm) |
| Coneyor type |
Chains |
| Threshing unit |
Main drum dimension |
¦µ600¡Á1800mm |
| Main drum type |
I¡¯ style= longitudinal flow |
| Drum quanity |
1 main thresher+ 1auxiliary reshresher |
| Concave |
4 Steel grids |
| Sieve |
Shaking sieve, adjustable |
| Cleaning type |
Shaking sieve + blowers + re-threshing |
| Blower type and qty |
Centrifugal type |
| Blower diameter |
¦µ350mm |
| Grain tank |
¡¡ |
1.3CBM |
| Grain discharging |
Hydraulic Auger Unloading, High postion unloading 270degree rotable |
| Note: Some specification, designs may be changed without prior notice. |
Feactures:
- Strengthened durable chassis, desinged for 10years.
- One lever lubrication function for chain system.
- Easy-Access-Design, openable thresher covers.
- Reverse Mechanism at conveyor and cutter table.
- Cabine with air conditioner.
Options:
- Extra kit for millet, rapeseed, corn, soybean, sorghum etc. crop.
- Straw crusher
- Straw Baler |
